"Training and laboratory equipment set "Hydraulic drive of agricultural machinery"
Description
The stand consists of a metal base with mounted hydraulic system and control elements, simulating a tractor hydraulic system.
Technical characteristics
Electric power supply: 220 V, 50 Hz.
Dimensions: 1500 x 1500 x 1400 mm.
Power consumption: 1.2 kW.
Weight: 500 kg.
Pressure: 160 bar.
Tank capacity: 5 litres.
Consumption: 3.7 l/min.
Purpose
Hydraulic drive for agricultural machinery" training-laboratory set (hereinafter - training stand) is designed for carrying out practical laboratory works on studying general arrangement and design of main assemblies and mechanisms of agricultural machines connected to hydraulic drive, their functioning principles and operating modes.
The equipment can be used for training in secondary and higher professional education institutions to gain basic and advanced knowledge and skills.
Composition
metal power frame,
hydraulic oil pumping unit,
hydraulic cylinder,
control panel,
rear linkage MTZ,
automatic coupling,
hydraulic control valve "
